Tenda TEG1008M LAN 8-Port 10/100/1000M Ethernet ports

TEG1008M is a high-performance 8-port full Gigabit desktop Ethernet switch designed for Tenda's high-speed cascading scenarios for small and medium-sized surveillance, small and medium-sized businesses. Designed with a mini steel shell, it does not take up space and has a strong heat dissipation. Provides 8 10/100/1000 Mbps auto-negotiation ports, which increases transmission rate by 10 times, improves large file forwarding rate, and effectively solves problems such as video jams and picture loss in high-definition surveillance environments. The TEG1008M supports desktop/wall mount installation, plug and play, no setup, easy to use, and is ideal for improving network performance. Standard&Protoco lIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab Interface 8*10/100/1000M RJ45 Ports Network Media Cat.5 UTP?Cat.5e UTP or better Forwarding Rate 10Mbps: 14880pps 100Mbps: 148800pps 1000Mbps: 1488000pps Powerinput: AC:190-240V 50/60Hz DC:9-12V Dimension 140*66.5*25.3mm(W*D*H) LED indicator 1*Power;8*Link/Act Switching Capacity 16Gbps MAC Address Table 4K Power Consumption Max :5W transmission mode Store-and-Forward ProtocolCDMA/CD MAC Address Learning Auto learning & auto aging Operating temperature: 0?~40?;Storage temperature: -40?~70? HumidityOperating humidit: 10%~90% non-condensing;Storage humidit: 5%~90% non-condensing Certification CCC, CE , FCC , RoHS Operation System Windows 8 32/64 bit?Windows 7 32/64 bit?Windows xp 32/64 bit?Linux?MAC OS Package Content 1 * 8-Port 10/100/1000M Ethernet Desktop Switch 1 * Power adapter 1 * Quick installation guide
