NB Lenovo ThinkPad T14 G1 i5-10210U16GB512GB14'' FHD IPSRJ-45Win10Pro20S1SF

PERFORMANCE

Processor

Intel® Core™ i5-10210U (4C / 8T, 1.6 / 4.2GHz, 6MB)

Graphics

Integrated Intel® UHD Graphics

Chipset

Intel® SoC Platform

Memory

16GB Soldered DDR4-2666

Memory Slots

One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable

Max Memory

Up to 48GB (16GB soldered + 32GB SO-DIMM) DDR4-2666

Storage

512GB SSD M.2 2280 PCIe® x4 NVMe® Opal

Storage Support

One drive, up to 128GB M.2 2242 SSD or 2TB M.2 2280 SSD, optional Intel® Optane™ Memory integrated with SSD, M.2

Card Reader

MicroSD Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers

Stereo speakers, 2W x2, Dolby® Audio™

Camera

720p with ThinkShutter

Microphone

2x, Array

Battery

Integrated 50Wh

Max Battery Life

MobileMark® 2014: 16.5 hr MobileMark 2018: 11.45 hr JEITA 2.0: 17.05 hr

Power Adapter

65W USB-C® (3-pin)

DESIGN

Display

14" FHD (1920x1080) IPS 250nits Anti-glare

Touchscreen

None

Keyboard

Backlit, ENG

Case Color

Black

Surface Treatment

Not Anti-microbial

Case Material

PPS / 50% GF (Top), PC + ABS / Talc15 + Magnesium Alloy (Keyboard Cover), PA / 50% GF (Bottom)

Dimensions (WxDxH)

329 x 227 x 17.9 mm (12.95 x 8.94 x 0.70 inches)

Weight

1.55 kg (3.41 lbs)

SOFTWARE

Operating System

Windows® 10 Pro 64, English

Bundled Software

None

CONNECTIVITY

Ethernet

100/1000M

WLAN + Bluetooth

Intel® AX201 11ax, 2x2 + BT5.2

WWAN

WWAN Upgradable to 4G

SIM Card

None

NFC

None

Standard Ports

·         1x USB 3.2 Gen 1

·         1x USB 3.2 Gen 1 (Always On)

·         1x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery and DisplayPort™ 1.2)

·         1x USB-C® 3.2 Gen 2 / Thunderbolt™ 3 (support data transfer, Power Delivery and DisplayPort™ 1.2)

·         1x HDMI® 1.4b

·         1x microSD card reader

·         1x Ethernet (RJ-45)

·         1x Headphone / microphone combo jack (3.5mm)

·         1x Side docking connector

Optional Ports (configured)

·         1x Smart Card Reader

·         1x Nano-SIM Card Slot

Docking

Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® T14 Gen 1 (Intel®)

Monitor Cable

None

SECURITY & PRIVACY

Smart Card Reader

Smart Card Reader

Security Chip

Discrete TPM 2.0

Fingerprint Reader

Touch Style, Match-on-Chip

Physical Locks

Kensington® Security Slot™

Other Security

ThinkShutter camera cover

MANAGEABILITY

System Management

Non-vPro®

SERVICE

Base Warranty

2-year

Included Upgrade

None

ACCESSORIES

Bundled Accessories

None

CERTIFICATIONS

Green Certifications

·         EPEAT™ Gold

·         ENERGY STAR® 8.0

·         RoHS compliant

Mil-Spec Test

MIL-STD-810G military test passed
