| Product Number | RR-212S-20PK-R2 (LGA1700 support for New Packaging Only) |
|
|
| CPU Socket | LGA1700, LGA1200, LGA2066, LGA2011-v3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, LGA1366, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1 | |
| Dimensions (L x W x H) | 123 x 77 x 158.8 mm / 4.78 x 3.0 x 6.3 inch | |
| Heat Sink Material | 4 Heat Pipes, Direct Contact, Aluminum Fins | |
| Fan Dimensions (L x W x H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch | |
|
| Fan Speed | 800-2000 RPM (PWM) ± 10% | |
|
| Fan Noise Level | 6.5 - 26 dBA | |
| Fan Air Pressure | 2.9 mmH2O | |
|
| Fan Power Connector | 4-Pin (PWM) | |
|
|
|
| Fan Power Consumption | 0.96W | |
|
|
|
|
